INTELLIGENT BALANCING TECHNOLOGY
Intelligent
balancing technology from a single source
· Highest manufacturing accuracy by balancing our tool holders with our balancing technology
· Highest precision by special measuring technology with a repeatability and measurement accuracy of < 0,4 gmm
· Power operated, secured clamping by high precision and unique constructed SCHÜSSLER balancing adapter
· Ergonomic design
· Balancing in one (static) as well as in two levels (dynamic)
Our balancing adapter –
precise and durable
The selection of high precise SCHÜSSLER balancing adapter with patented construction allow above average high repeatability and measurement accuracy of HSK and SK adapter.
HSK-ADAPTER – HSK 32/40/50/63/80/100 A/C/E-B/D/F
- Power operated tool clamping with power spring package
- High reproducibility and repeatability · Draw bolt with ejector
- for easy change of the tool holder
- Maximum repeatability thanks to a tool holder without radial or axial clearance
- Certied safety at adapter change
SK-ADAPTER – SK 30/40/50
- Universal patented tool clamping system allows clamping of tool holders with any type
of tightening bolt - Power operated tool clamping with power spring package
- High reproducibility and repeatability
- Maximum repeatability thanks to a
tool holder without radial or axial clearance - 5-point-system for backlash-free pickup of the steep taper*
- Certied safety at adapter change
- Balancing of SK-Adapters without tightening
bolt possible
*U sable for various balancing devices of another producer
** Further adapter on demand
